PLC Controller Power Press Punching Machine Hydraulic Overload Protection

PLC Controller Punching Press Machine And Power Press For Whole Line Service

Features:

1. This machine adopts Siemens CPU216 programmable logic container(PLC) as the controlling system. It is reliabale. The feeding length, producing speed and other parameter are easily set. It is integration of Gas & Electrical, centralized control, automated production.
2. Feeding, punching, scrap collecting is running automatically.
3. The accurate press adopts steel plates joining body, variable frequency speed regulation, dry type friction clutch to clutch-on-off,rigid over-load protector to protect the press. In short, this is a high accuracy and reliability press.
4. Feeding is controlled by stepper system, the feeding length is accurate and can be adjusted from 20mm to 999mm.

High Precision Presses Standard Accessories

• Hydraulic overload protection device
• Manual type, electrical Lubrication uncrating device
• Slider and die balance device
• The rotary cam controller
• Pointer crankshaft angle display
• Intelligent travel counter
• The shockproof rubber cushion or mechanical foot slider expected device
• The main motor reversing device
• The operating instructions

Optional accessories

• The slider expected device
• Pneumatic die cushion lifting device
• Photoelectrical safety device
• Mould lighting device
• Preload counter
• Preset counter
• Check how dead the next
• The foot operated switch
• For mold, mold clamp mold moving arm or
• Feeding machine, feeder, leveling machine
• Electronic crank angle display • Air source socket
• The air blowing device
• The variable frequency variable speed motor
• The fault detecting device
• The power supply socket
• Maintenance tools and tool kit

Specification
